SM-AF12 Long Distance Fixed RFID Antenna

Category:Fixed RFID Reader Antenna

Product ID:SM-AF12

Views:2003

Product Introduction:SM-AF12 antenna offers high gain, ruggedness and excellent shock and vibration resistance in a unique design.




Inquiry Now

Details

SCANMAX - the global RFID technology provider - is a leading developer and manufacturer of high quality, intelligent RAIN RFID (UHF) and NFC (HF) inlays, tags and connectivity solutions utilized in the Internet of Things (IoT). With a focus on RFID innovation, SCANMAX has created a leading product line in retail, library, pharmaceutical, healthcare, (public) transportation and many other industries.


SCANMAX SM-AF12 antenna offers high gain, ruggedness and excellent shock and vibration resistance in a unique design. The SM-AF12 circular polarized antenna is ideal for transportation, logistics, warehousing and asset tracking applications.


Product Features:
• Operating Frequency 840 - 928 MHz
• High Gain
• Circular Polarization
• Low VSWR
• Protection Level: IP65F
• Durable and clean design
• Simple installation and maintenance


Product Parameters:

Performance Parameter
Operating Frequency 840 - 928 Mhz
VSWR ≤ 1.3:1
Gain 7.15 dBi
H-Plane HPBW 60°
E-Plane HPBW 60°
Polarization Circular
Antenna Impedance 50 Ω
Environmental
Operating Temperature -40°C to 70°C (-40°F to 158°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Humidity Range 5% - 95% RH
Protection Level IP65
Physical Parameters
Dimensions 291 x 291 x 52 mm; 11.5 x 11.5 x 2 in
Weight Approx. 0.91 kg / 2.0
Case Material Lbs Plastic ASA, Aluminium



Radiation Pattern


Mounting Bracket
